Darkglass

NSG

NSG

$229.99 USD
$229.99 USD
Sale Sold out
Shipping calculated at checkout.

The Darkglass Noise Gate Spot Series effects pedal comes as a response to having extraneous noise in your bass rig. The adjustable threshold level control will filter out sounds below a certain threshold, allowing for only the desired audio signal to be heard.

View full details

Enhancing quietness

The NSG: Noise Gate comes as a response to these annoyances. Utilizing an adjustable threshold level to filter out sounds below a certain threshold, allowing for only the desired audio to be seized.

Video thumbnail

Front features

  • Threshold

    Use this push knob to control the threshold of the noise gate. Press the knob to switch between the “Soft” mode (Blue LED color) for softer gain reduction and “Hard” (Red LED color) for the more aggressive gate operation.

  • Threshold range

    From -65 dBV to -30 dBV in “Soft” mode.
    From -45 dBV to +5dBV in “Hard” mode.

  • Dimensions

    Width: 50 mm /2″
    Length: 36,5 mm/ 1 ½″
    Height: 100 mm / 4″
    Weight: 205 g / 0,45 lb

  • Technical Specifications

    Input Impedance: 1 MΩ
    Output Impedance: 100 kΩ
    Current Consumption: ~60 mA
    Voltage 9V DC (Center Negative)

  • Warning

    The NSG Noise Gate has a current draw of 60 mA. Only use a regulated 9V DC adapter with a center-negative plug.

    Unregulated power supplies and/or higher voltages may result in suboptimal noise performance and even damage your unit, voiding the warranty.

1 13

SUPPORT + DOCUMENTATION

SUPPORTREGISTER YOUR PRODUCT

DISCLAIMER

In the interest of continuous improvement, specifications are subject to change without notice. If you have any questions, please don’t hesitate to contact us at www.darkglass.com

The manufacturer claims that the above product fulfills the requirements as set by EN55013, EN55020, EN60555-2, EN60555-3, RoHS, WEEE.
