Hyper Luminal

Enhancer Series

Hybrid Compressor.



The Hyper Luminal Compressor features the first hybrid design in a compressor pedal: an analog VCA controlled by a digital side-chain allowed us to capture and include the characters of some of the most legendary compressors in history while keeping the signal path completely analog.

Specs

Blend

Mixes the clean and effected signals. Unlike our distortions, it is placed before the Output control. So the Hyper Luminal can also be used as a transparent booster with this control at minimum.



Time

Sets the time constants (Attack and Release). You can use the Darkglass Suite to fine tune and custom map the time constants, you can also assign different behaviours for each Mode.



Output

Sets the overall output volume of the unit.

Compression

Sets the overall amount of compression. This control also affects the internal makeup gain.



Ratio

Adjusts the amount of compression.



Mode

Selects the unit’s Mode (BUS, FET, or SYM).

Dimensions

Width: 75 mm / 3″
Length: 111 mm/ 4¼″
Height: 43 mm / 1¾″
Weight: 250 g / 0.55 lb



Warning

The Hyper Luminal has a current draw of 250mA. Only use a regulated 9V DC adapter with a center-negative plug.

Unregulated power supplies and/or higher voltages may result in suboptimal noise performance and even damage your unit, voiding the warranty.

All product names are trademarks of their respective owners, which are in no way associated or affiliated with Darkglass Electronics.

Touch Sensors

Ratio

Adjust the amount of compression ratio.

  • BUS: 2:1, 4:1, 10:1, 15:1
  • FET: 2:1, 4:1, 8:1, 20:1, “ALL IN”
  • SYM: Based on different settings of the Super Symmetry · 115 GeV Compressor.



Mode

Selects between three different models:

  • BUS: Modeled after the Solid State Logic ® Bus compressor.
  • FET: Inspired by the legendary 1176®.
  • SYM: Our discontinued Super Symmetry · 115 GeV Compressor.

Darkglass Suite



By using the desktop version of the Darkglass Suite you can adjust the time and attack settings of each mode, the side chain parallel high pass filter, the mode of the release and attack settings and enable or disable the “guitar” mode.

Input & Outputs

Output

Connect from the ¼” Output jack to the input of your amplifier or another effects pedal.

Input

Connect your instrument or output from your pedal board to the ¼” mono jack.

USB

A USB C connector allows you to connect the pedal to PC/Mac to set Time settings, parameters, and future firmware upgrades via the Darkglass Suite.

9V DC

Only use a regulated 9V DC adapter with a center-negative plug.

Disclaimer

In the interest of continuous improvement, specifications are subject to change without notice. If you have any questions, please don’t hesitate to contact us at www.darkglass.com

The manufacturer claims that the above product fulfills the requirements as set by EN55013, EN55020, EN60555-2, EN60555-3, RoHS, WEEE.
