Darkglass

Microtubes B3K V2

Microtubes B3K V2

£197.00 GBP
£197.00 GBP
Sale Sold out
Shipping calculated at checkout.
  • The natural dynamics and organic compression of vintage tube amps and tape machines
  • Level control sets the volume of the overdrive signal
  • Drive control sets the amount of saturation in the overdrive signal
  • Blend controls bring your clean signal back in
  • Grunt switch lets you select the amount of LF content to be saturated
  • Mid boost button brings back frequencies that can be lost with other drive pedals
  • Power requirements: regulated 9-volt DC adapter with center-negative plug



View full details

Design and Tone. Perfected

With the Microtubes B3K v2, you get all the features of the original, with the ability to restore the mids for natural character. The attack switch has been replaced by the tone knob, giving much more control of the higher harmonic content (3 kHz to 8 kHz). The grunt switch is still present, as you would expect. The addition comes in the form of a mid boost, giving you a subtle 6dB boost from 300 Hz to 1 kHz to help you cut through a bit more.

Fundamentally, the Microtubes B3K is the same pedal we designed nearly a decade ago, aimed to give you a perfect combination of brutality and clarity. You can guarantee that this pedal will deliver defined and powerful saturation in an intuitive format.

Video thumbnail

Specs

  • Blend

    Mixes the clean input signal with the overdriven signal. The clean signal remains at unity gain while the volume of the overdriven signal is set by the Level knob, allowing for fine control of the blend ratio.

  • Mid Boost

    Gives a subtle 6dB boost from 300 Hz to 1kHz to help you cut through a bit more.

  • Dimensions

    Width: 75 mm / 3″
    Length: 111 mm/ 4¼″
    Height: 43 mm / 1¾″
    Weight: 250 g / 0.55 lb

  • Tone

    Controls the high frequency content of the sound. A variable low pass filter from 3kHz (ccw) to 8kHz (cw).

  • Output

    Connect from the ¼” Output jack to the input of your amplifier or another effects pedal.

  • Warning

    The Microtubes B3K has a current draw of 20mA. Only use a regulated 9V DC adapter with a center-negative plug.

    Unregulated power supplies and/or higher voltages may result in suboptimal noise performance and even damage your unit, voiding the warranty.

  • Level

    Sets the volume of the overdriven signal.

  • Input

    Connect your instrument or output from your pedal board to the ¼” mono jack.

  • Drive

    Sets the amount of saturation in the overdriven signal.

  • 9V DC

    Only use a regulated 9V DC adapter with a center-negative plug.

  • Grunt

    When engaged provides a massive low end boost to really thicken your sound.

1 13

SUPPORT + DOCUMENTATION

SUPPORTREGISTER YOUR PRODUCT

DISCLAIMER

In the interest of continuous improvement, specifications are subject to change without notice. If you have any questions, please don’t hesitate to contact us at www.darkglass.com

The manufacturer claims that the above product fulfills the requirements as set by EN55013, EN55020, EN60555-2, EN60555-3, RoHS, WEEE.
